Automatic foil and baking paper rewinder with the dotting line JZ-500L-4D
Enquiry nowAutomatic foil and baking paper rewinder with the dotting line
Electronic part for the machine: JZ-500L-4D
PLC
OMRON, Japan
METER COUNTER
OMRON, Japan
POWER SWITCH
OMRON, Japan
INVERTER
DELTA, Taiwan
TOUCH SCREEN
DELTA, Taiwan
LOW VOLTAGE APPARATUS
SCHNEIDER, Japan
Parameters： | |
Model | JZ-500L-4D |
Material | Aluminum foil, baking paper |
Width of material | 250-500mm |
Max.dia of Jumbo roll | 600mm |
Rewinding length | 2.0-80 m |
Thickness of the foil | 0.008-0.05mm |
Speed | 0-200 m/min |
ID of Jumbo roll | 3 inch（76mm） |
ID of of paper core size | 28-50mm |
Power of main motor | 2.2 KW |
Gross power | 4KW |
Overall dimension | 1620 x 2200 x 2200mm |
Weight | 1.5T |
Electronic part： | |
PLC | OMRON |
Meter counter | OMRON |
Power box | OMRON |
Inverter | Delta |
Touch screen | Delta |
Relay | Schneider |
Contact | Schneider |
Auto tension controller | Japan |
Sensor | Taiwan |
Mechnical valve | Taiwan |
